Elevator Cable Application
These power and control flat cables can be used on festooned systems on handling equipment as overhead cranes. They are designed for indoors and outdoors for ambient temperature down to -25°C.These cables can accept a trolley traveling speed up to 120m / min.
Elevator Cable Technical Data
Voltage Rating :
H05VVH6-F – 300/500V
H07VVH6-F – 450/750V
Colour Coding :
Core 1: Black.
Core 2: Light-blue.
Core 3: Green-yellow.
Core 4: Brown.
Core 5: Black.
Core 6 and above: All black numbered cores with one green / yellow earth core.
Elevator Cable Design Parameters
| Nominal Cross-Sectional Area (Sq. mm) | Overall Dimensions (mm) | Permissible Current Rating (A) | Voltage Drop (ΔU) at cos Φ = 0.8 (V/A x km) | Approx. Weight (kg/km) |
| 4 x 1.5 | 15.0 x 5.0 | 20 | 20.2 | 150 |
| 4 G 1.5 | 15.0 x 5.0 | 20 | 20.2 | 150 |
| 4 G 2.5 | 18.5 x 5.7 | 27 | 12.3 | 210 |
| 4 G 4 | 21.0 x 6.5 | 36 | 7.8 | 300 |
| 4 G 6 | 23.0 x 7.0 | 48 | 5.3 | 385 |
| 4 G 10 | 28.8 x 9.0 | 63 | 3.2 | 620 |
| 4 G 16 | 36.8 x 10.8 | 85 | 2 | 990 |
| 4 G 25 | 45.5 x 13.5 | 112 | 1.3 | 1550 |
| 4 G 35 | 50.5 x 14.8 | 138 | 0.97 | 2030 |
| 4 G 50 | 56.0 x 16.5 | 168 | 0.74 | 2650 |
| 4 G 70 | 63.0 x 18.0 | 213 | 0.55 | 3650 |
| 4 G 95 | 72.5 x 20.5 | 258 | 0.42 | 4550 |
| 5 G 1.5 | 18.0 x 5.0 | 18 | 20.2 | 180 |
| 5 G 2.5 | 22.0 x 5.7 | 25 | 12.3 | 260 |
| 5 G 4 | 27.0 x 6.5 | 36 | 7.8 | 380 |
| 5 G 6 | 27.0 x 7.0 | 48 | 5.3 | 480 |
| 5 G 10 | 34.5 x 9 | 63 | 3.2 | 780 |
| 7 G 1.5 | 26.0 x 5.0 | 15 | 20.2 | 260 |
| 7 G 2.5 | 32.3 x 5.7 | 20 | 12.3 | 380 |
| 7 G 4 | 40.0 x 6.8 | 25 | 7.8 | 550 |
| 8 x 1.5 | 29.0 x 5.0 | 14 | 20.2 | 300 |
| 8 G 1.5 | 29.0 x 5.0 | 14 | 20.2 | 300 |
| 8 G 2.5 | 34.5 x 5.7 | 20 | 12.3 | 405 |
| 10 G 1.5 | 35.0 x 5.0 | 12 | 20.2 | 360 |
| 12 G 1 | 33.5 x 4.5 | 8 | 38.2 | 320 |
| 12 x 1.5 | 40.5 x 5 | 11 | 20.2 | 420 |
| 12 G 1.5 | 40.5 x 5 | 11 | 20.2 | 420 |
| 12 G 2.5 | 50.5 x 5.7 | 16 | 12.3 | 620 |
| 12 G 4 | 57 x 6.8 | 20 | 7.8 | 880 |
| 14 G 1.5 | 47.5 x 5 | 11 | 20.2 | 490 |
| 16 G 1.5 | 53.5 x 5 | 10 | 20.2 | 560 |
| 18 G 1 | 50.5 x 4.5 | 6 | 38.2 | 470 |
| 18 G 1.5 | 58.0 x 5.0 | 8 | 20.2 | 620 |
| 24 G 1 | 6.5 x 4.5 | 6 | 38.2 | 610 |
Note:H05VVH6-F Cables
Electrical Parameters
