(N)GFLCGÖU Screened Flat Festoon Cable
(N)GFLCGÖU Screened Flat Festoon Cable especially used for lifts, cranes, floor conveyor systems, elevators and festoon systems. Flat structure means suitable for installations where space is at premium and requires smaller bending radius. Copper screens are efficient against electromagnetic effects. Not suitable for torsional stress.
(N)GFLCGÖU Screened Flat Festoon Cable Application
Especially used for lifts, cranes, floor conveyor systems, elevators and festoon systems. Flat structure means suitable for installations where space is at premium and requires smaller bending radius. Copper screens are efficient against electromagnetic effects. Not suitable for torsional stress.
(N)GFLCGÖU Screened Flat Festoon Cable Chracteristics
| Voltage Rating (Uo/U) | 300/500V |
| Temperature Rating | Flexed: -50°C to +90°C Mobile: -30°C to +90°C Maximum Conductor Operating Temperature: 90°C Maximum Conductor Short-Circuit Temperature: 250°C |
| Minimum Bending Radius | Fixed Application: 5 x Overall Diameter |
| Mobile Applications: 10 x Overall Diameter | |
| Maximum Tensile Load | 15 N/mm² |
| Maximum Torsion | ±25º/m |
| Travel Speed | Festoon Systems Up to 180m/min |
| Gantry (reeling): No application |
(N)GFLCGÖU Screened Flat Festoon Cable Construction
| Conductor | Up to 25mm2: Class 6 electrolytic annealed, plain copper 25mm2 an above: Class 5 electrolytic annealed, plain copper |
| Insulation | EPR (Ethylene Propylene Rubber) |
| Screen | TCWB (Tinned copper wires braiding) |
| Sheath | CR (Chloroprene Rubber) type 5GM3 |
| Core Identification | 4 Core: Green/Yellow Brown Black Grey 5 Core: Green/Yellow Blue Brown Black Grey 7 Core and above: Black with white numbering |
(N)GFLCGÖU Screened Flat Festoon Cable Standards
VDE0293-308, DIN VDE 0250-809, DIN VDE 0250-1, DIN VDE 0298-3, DIN VDE 0472-501, 503, 508, DIN VDE 0472-401, 402, 602, 303, 615, DIN VDE 0472-803, 804, VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1, HD/EN/IEC 60811-2-1, DIN VDE 0473-811-2-1
