Reelflex PUR-H Drum Reeling Cable

Name: Reelflex PUR-H Drum Reeling Cable
Availability: InStock

Voltage Rating:
Working: 0.6/1kV
Test: 2500V

Temperature Rating:
Static: -50°C to +80°C
Flexing: -40°C to +80°C

Bending Radius:
Flexing: 6 x cable diameter

Inquiry

Send Email

Reelflex PUR-H Drum Reeling Cable Description:

Reelflex PUR-H Drum Reeling Cable is part of the latest generation of drum reeling cables. When compared to the standard rubber NSHTöu, Reelflex PUR-H Drum Reeling Cable is significantly smaller in overall diameter and lighter in weight. This allows the use of lighter winding/reeling equipment offering considerable cost savings. Ideal for use inside or in the open air, these cables emit very little smoke and are halogen free, making them suitable for sensitive applications in the event of fire.

Reelflex PUR-H Drum Reeling Cable Construction:

Fine copper strands to IEC 60228 insulated with halogen free polyester, cores laid around a central textile suspension unit using a short length of twist. Anti-torsion braid embedded between the inner and outer halogen free black polyurethane sheath. Some large sizes may have a split earth construction. Please check at time of order if this is critical.

Reelflex PUR-H Drum Reeling Cable Spec:

Description	Cores	mm²	Colour	Sheath
4 x 1.5mm² Reelflex PUR-H Drum Reeling Black PUR	4	1.5	Black	PUR
5 x 1.5mm² Reelflex PUR-H Drum Reeling Black PUR	5	1.5	Black	PUR
7 x 1.5mm² Reelflex PUR-H Drum Reeling Black PUR	7	1.5	Black	PUR
12 x 1.5mm² Reelflex PUR-H Drum Reeling Black PUR	12	1.5	Black	PUR
18 x 1.5mm² Reelflex PUR-H Drum Reeling Black PUR	18	1.5	Black	PUR
24 x 1.5mm² Reelflex PUR-H Drum Reeling Black PUR	24	1.5	Black	PUR
30 x 1.5mm² Reelflex PUR-H Drum Reeling Black PUR	30	1.5	Black	PUR
42 x 1.5mm² Reelflex PUR-H Drum Reeling Black PUR	42	1.5	Black	PUR
4 x 2.5mm² Reelflex PUR-H Drum Reeling Black PUR	4	2.5	Black	PUR
5 x 2.5mm² Reelflex PUR-H Drum Reeling Black PUR	5	2.5	Black	PUR
7 x 2.5mm² Reelflex PUR-H Drum Reeling Black PUR	7	2.5	Black	PUR
12 x 2.5mm² Reelflex PUR-H Drum Reeling Black PUR	12	2.5	Black	PUR
18 x 2.5mm² Reelflex PUR-H Drum Reeling Black PUR	18	2.5	Black	PUR
24 x 2.5mm² Reelflex PUR-H Drum Reeling Black PUR	24	2.5	Black	PUR
30 x 2.5mm² Reelflex PUR-H Drum Reeling Black PUR	30	2.5	Black	PUR
36 x 2.5mm² Reelflex PUR-H Drum Reeling Black PUR	36	2.5	Black	PUR
4 x 4.0mm² Reelflex PUR-H Drum Reeling Black PUR	4	4	Black	PUR
5 x 4.0mm² Reelflex PUR-H Drum Reeling Black PUR	5	4	Black	PUR
4 x 6.0mm² Reelflex PUR-H Drum Reeling Black PUR	4	6	Black	PUR
5 x 6.0mm² Reelflex PUR-H Drum Reeling Black PUR	5	6	Black	PUR
4 x 10mm² Reelflex PUR-H Drum Reeling Black PUR	4	10	Black	PUR
5 x 10mm² Reelflex PUR-H Drum Reeling Black PUR	5	10	Black	PUR
4 x 120mm² Reelflex PUR-H Drum Reeling Black PUR	4	120	Black	PUR
4 x 150mm² Reelflex PUR-H Drum Reeling Black PUR	4	150	Black	PUR
4 x 16mm² Reelflex PUR-H Drum Reeling Black PUR	4	16	Black	PUR
5 x 16mm² Reelflex PUR-H Drum Reeling Black PUR	5	16	Black	PUR
4 x 25mm² Reelflex PUR-H Drum Reeling Black PUR	4	25	Black	PUR
4 x 35mm² Reelflex PUR-H Drum Reeling Black PUR	4	35	Black	PUR
4 x 50mm² Reelflex PUR-H Drum Reeling Black PUR	4	50	Black	PUR
4 x 70mm² Reelflex PUR-H Drum Reeling Black PUR	4	70	Black	PUR
4 x 95mm² Reelflex PUR-H Drum Reeling Black PUR	4	95	Black	PUR
